Protection rating (EN 60529): IP67
Dial: White, Aluminium
Pointer: Black, Aluminium, Adjustable
Window material: Instrument glass
Nominal size: 130 mm
Case material: Stainless steel 1.4301 / AISI 304
Bezel ring material: Stainless steel 1.4301 / AISI 304
Temperature range: -70°C ... +600°C / -100°F ... +1100°F
Wetted parts: Immersion tube material: Stainless steel 1.4571 / AISI 316Ti
Minimum immersion length for immersion tube 6 mm L2 ≥ 65 mm
Minimum immersion length for immersion tube 8 mm L2 ≥ 50 mm
Performance: Accuracy according to EN 13190 ≤ 250°C: Class 1 / > 250°C: Class 2 (Class 1 on request)
Electrical data: ATEX: Ex II 2 GDc (with option 0078)
