Nominal size: 100 mm
Case material: Stainless steel 1.4301 / AISI 304
Bezel ring material: Stainless steel 1.4301 / AISI 304
Window material: Instrument glass
Window gasket: Elastomer
Protection rating (EN 60529): IP54, not filled / IP65, filled
Dial: White, aluminium
Pointer: Black, aluminium
Movement material: Brass
Wetted parts: Process connection material: Brass
Bourdon tube: Bronze
Performance: Accuracy according to EN 837-1 Class 1
Min. measuring range 0 ... 0.6 bar / Max. measuring range 0 ... 60 bar
