Nominal size: 63 mm
Case material: Monel 400
Bezel ring material: Stainless steel 1.4404 / AISI 316L
Window material: Instrument glass
Window gasket: Elastomer
Protection rating (EN 60529): IP65
Dial: White, Aluminium
Pointer: Black, PVA
Movement material: Stainless steel
Safety according to EN 837-1: S1, with window polycarbonate or Laminated safety glass
Wetted parts: Process connection material Monel 400
Bourdon tube: Monel 400
Performance: Accuracy according to EN 837-3 Class 1.6
Min. measuring range 0 ... 1 bar / Max. measuring range 0 ... 400 bar
Approval / Conformities ATEX Ex II 2 GDc-IM2c
