Nominal size: 150 mm
Case material: Stainless steel 1.4301 / AISI 304 (316L optional)
Bezel ring material: Stainless steel 1.4301 / AISI 304 (316L optional)
Window material: Instrument glass
Window gasket: Elastomer
Protection rating (EN 60529): IP66
Dial: White, Aluminium
Pointer: Black, Aluminium
Movement material: Brass
Process connection G1/2" / 1/2" NPT
Capsule: Stainless steel 1.4404 / AISI 316L
Performance: Accuracy ± 2 %
Min. measuring range 0 ... 10 mbar / Max. measuring range 0 ... 250 mbar
