Please note any Burkert products listed on this page are sold at a highly reduced cost and therefore will not be eligible for return, exchange or refund. We appreciate that full technical details for individual items may not be displayed so please feel free to call our sales team on +44 (0) 800 328 8511 if you would like further information before purchasing.
Type 6213 solenoid valve
Circuit function A 2/2-ways; normally closed
Orifice size DN 25,0 25mm (1")
Seal material NBR Body brass
Port connection LTA GM87 G1 1/4 threaded port
Voltage 230 volts 50 Hz 16 watt
Type 6519 Pneumatic Valve, 5/2 Way or 3/2 Ways, 6mm Orifice Size, 1/4" BSP Ports, 0.3 Watt *HA01 without manual override *MT66 pilot made of BR *MT68 high-ohmic version Inenn = 23mA *PD94 approval PTB 01 ATEX 2101 AC10, coil size 6 diodes in the coil II 2GEx ia IIC T6 Gb & II 2D Ex ia IIIC T80°C Db/IECEx PTB 12.0040
A closed by spring force
2 2 ways / 2 position
40.0 Orifice size DN 40 (1 1/2")
EE Seal material PTFE
RG Body material gunmetal
GM88 Port connection G1 1/2 threaded port
ANTA Actuator version, MS-threaded bushing at connection of pilot air
ANTG Actuator 80mm
Special Feature VAR1 AF12 short body
VAR2 LE07 max. stroke limitation
Wall mounted IP 65 flow meter / transmitter, LED display, Choice of engineering units, Display - 1 x Flow, 2 x totals, 115 - 230 powered. 4-20mA, pulse output.
Type 8025 flow transmitter insertion (l/min)
function sensor FKTS F4 measurement, pulse output, totalizers
Design AUFB F PC-case, IP65, wall mounting display
Voltage SP BBM 110-230 volts
Output signal AUSG G output current 4-20mA with relay
Special Feature VAR1 MT25 230V-version
type S030 FLUID SENSORbody
port connection MS31 M55 X 2 CONNECTION
body material MS BRASS
seal material FF FKM
sensor P5 PVDF PADDLEWHEEL WITH INDUCTIVE COIL
Type S010 flow switch
Port connection LTA KM25 solvent crement socket, diam. 20mm
Body material WKST PV PVC
Seal material DWST FF FKM
Sensor SEN D1 flow meas. range 1 (for DN 15 -50)
Series 6518 3/2 solenoid/spring pilot valve with 1/4NPT ports and 24vdc operation
complete with a 500mm long flying lead connection and it is FM approved.
Our team of engineers are fully equipped to provide bespoke system design and manufacture.
This process involves specifying, procuring, calibrating and maintaining instrumentation and control systems for industrial and commercial process control applications.
